NE plate chain bucket elevator
NE plate chain bucket elevator---new spare part of grinding plant
 Introduction of NE plate chain bucket elevator:
The NE plate chain bucket elevator series are a kind of advance vertical elevators domestically, They are characterized by large conveying capacity, small driving power, high lifting height and wide lifting range. It is widely sued to lift materials in bulk, e.g. ore, coal, cement chamotte, foodstuff and so on.

Features of NE plate chain bucket elevator:
***NE Bucket Elevator
***Large conveying capacity
***Small driving power
***High lifting height
***Small maintenance
Technology Data of NE plate chain bucket elevator:
Model Capacity (m3/h) Max. particle size (mm) Material bulk density (t/m3) Max. lifting height (m) Motor Power (KW)
NE15 10-15 40 0.6-2.0 35 1.5-4
NE30 18.5-31 55 0.6-2.0 50 1.5-11
NE50 35-60 60 0.6-2.0 45 1.5-18.5
NE100 75-110 70 0.6-2.0 45 5.5-30
NE150 112-165 90 0.6-2.0 45 5.5-45
NE200 170-220 100 0.6-1.8 40 7.5-55
NE30 230-340 125 0.6-1.8 40 11-75
NE400 340-450 130 0.6-1.8 30 18.5-90
NE500 450-550 140 0.6-1.8 30 30-110
NE600 550-660 150 0.6-1.8 30 37-132
NE800 680-830 165 0.6-1.8 30 37-160
